Climatic Chamber DRACARYS SPEED

Key Features

• Available volumes: 80 L – 1 500 L

• Extreme temperature range: −70 °C ÷ +180 °C

• Controlled humidity: 10 % – 98 % RH

• Climatic stability / uniformity: ±0.1 °C ; ±1 % RH

• Custom versions: on request

• Temperature sub‑ranges: A:+25 °C | B:0 °C | C:−20 °C | D:−40 °C | E:−50 °C | F:−60 °C | G:−70 °C

• Relative‑humidity range: 20 %‑98 % RH (optionally 10 %‑98 % RH or 5 %‑98 % RH)

• Operating climatic field: +10 °C ÷ +90 °C

• Sensor accuracy / uniformity (T / RH): 0.01 °C ; ±0.19 % RH ; ±1.0 °C ; ±3.0 % RH

• System accuracy / stability (T / RH): ±1.0 °C ; ±2.0 % RH

• Model FX: mean unloaded variation rate per IEC 60068‑3‑5 (value = °C /min)

• Model X: linear variation rate per IEC 60068‑3‑5 (value = °C /min)

• Compressor brands: Copeland / Bitzer

• Power supply: 400 V ±10 % · 50 Hz · 3 + N + G

---

Standard Equipment

• External / internal materials: galvanised‑steel frame painted RAL 9005 / 7042 / 7201 / 5005, textured finish; 304 stainless‑steel inner tank

• Remote supervision via GSM router with remote‑assistance service

• Insulation: high‑density polyurethane foam + rock wool

• Condensation options: air‑cooled / water‑cooled

• Control system: DOT 10″ Touch Panel with “ClimaLogiC” software

• Data logging, test‑profile storage and full parameter management

• Ethernet & USB ports for export and remote control

• Smart alarms with multi‑user safety

• Optimised air circulation for climatic uniformity

• Inspection window, internal lighting, ergonomic door

• High‑precision capacitive probe

• Castors / adjustable feet, Ø 80 mm port, 2 stainless shelves

• Air‑ or water‑cooled condensing unit with F‑Gas‑compliant refrigerants

• Multi‑chamber remote control

---

Optional Extras

• Additional feed‑throughs, electric locks, door gloves

• F‑Gas‑compliant refrigerants (alternate blends)

• Sound‑proofing kit: noise reduction up to 3 dB(A)

• EUCAR abuse‑test bench for Li‑ion batteries

• Safety Glycol package: ethylene‑glycol cooling, leak sensors, auto‑shut‑off

• Custom specimen racks / shelves

• Solar simulation, multi‑colour visual alarms, remote units

• Cryogenic kits, dry‑air purge, extra dryers & humidifiers

• Digital / analogue I/O, safety thermostats, special valves

• Demineralised‑water treatment & management
